Material of Construction | |||
Parts | Carbon Steel | Stainless Steel 304 | Stainless Steel 316 |
Base Flange | IS 2062 / A 105 | SS 304 | SS 316 |
Water Barrel | IS 1239 Part I Seamless A106 Gr. B | SS 304 | SS 316 |
Swivel Joint | Bronze | SS 304 | SS 316 |
Bends | Carbon Steel IS 4310 | SS 304 | SS 316 |
Handwheel | SS 304 | SS 304 | SS 304 |
Nozzle | Aluminum IS 617 / Gun Metal IS 318 LTB – 2 / SS 304 / 316 / IS 3444 Gr. I / IV | ||
Flame Proof Motor for Horizontal, Verticle Movement & Nozzle Movement | Kirlosker / HEL | ||
Flame Proof Monitor Operation Panel | Flameproof Equipment / SUHIR | ||
Operational & Technical Data | |
Working Pressure (For Foam Equp.) | 5 to 10 Kgf/cm2 |
Manouverability | +900/ -450in vertical plane and 3600in horizontal Plane |
Finish | Painted with Red Color (As per Customer Requirements |
Model No. | Operation Pressure | Nozzle | Inlet | Performance* RangeLPM | Material ofConstruction | |
VFWM-5710-CS | 6 – 12 Kg / Cm2 | Aqua Foam Nozzle | 150 NB Flange 150 mm Water Way | 65 Mtrs. (#) Water Throw | 1850 (500 GPM) | CS & (SS / AL) |
VFWM-5710-SS | 6 – 12 Kg / Cm2 | 75 Mtrs. (#) Water Throw | 2850 (750 GPM) | SS & (SS / AL) | ||
VFWM-5710-SM | 6 – 12 Kg / Cm2 | 85 Mtrs. (#) Water Throw | 3800 (1000 GPM) | SM / (SS / AL) | ||
VFWM-1020-CS | 7 – 12 Kg / Cm2 | Aqua Foam Nozzle | 200 NB Flange 200 mm Water Way | 65 Mtrs. (#) Water Throw | 3800 (1000 GPM) | CS & (SS / AL) |
VFWM-1020-SS | 7 – 12 Kg / Cm2 | 85 Mtrs. (#) Water Throw | 7575 (2000 GPM) | SS & (SS / AL) | ||
VFWM-1020-SM | 7 – 12 Kg / Cm2 | 95 Mtrs. (#) Water Throw | 11130 (3000 GPM) | SM / (SS / AL) | ||
