General Data | |
Model | Stand Post Type, Manual Swivel |
Inlet | Flanged 75 – 100 – 150 NB IS:1538 / ANSI B 16.5 150# |
Outlet | Threaded Mounting attached Super Jet Nozzle |
Material of Construction | |||
Parts | Carbon Steel | Stainless Steel 304 | Stainless Steel 316 |
Base Flange | IS 2062 / A 105 | SS 304 | SS 316 |
Water Barrel | IS 1239 Part I Seamless A106 Gr. B | SS 304 | SS 316 |
Swivel Joint | Bronze | SS 304 | SS 316 |
Bends | Carbon Steel IS 4310 | SS 304 | SS 316 |
Handwheel | SS 304 | SS 304 | SS 304 |
Nozzle | Aluminum IS 617 / Gun Metal IS 318 LTB – 2 / SS 304 / 316 / IS 3444 Gr. I / IV | ||
Testing and Quality Control | ||||||
Model | Operating Pressure | Flow Range (LPM) | Barrel Size | Inlet Flange | Flow (LPM) | Range (Meters) |
KFP 1750 | 6 – 12 Kg / Cm2 (g) | 1500 – 2500 | 63 | 75 / 100 | 1750 | 55 |
KFP 2580 | 1800 – 3500 | 75 | 100 | 2580 | 60 | |
KFP 3750 | 7 – 12 Kg / Cm2 (g) | 2500 – 5500 | 100 | 100 / 150 | 3750 | 65 |
Operational & Technical Data | |
Working Pressure (For Foam Equp.) | 5 to 10 Kgf/cm2 |
Manouverability | +900/ -450in vertical plane and 3600in horizontal Plane |
Finish | Painted with Red Color (As per Customer Requirements |
Model No. | Operation Pressure | Flow Range | Inlet | Performance* Range LPM | Material ofConstruction | |
SJWM-1750/CS/IS | 6 – 12 Kg / Cm2 | 1500 – 2500 | 75 / 100 NB Flange | 55 Mtrs. | 1750 | CS & (SS / AL) |
SJWM-1750/CS/NS | 6– 12 Kg / Cm2 | CS & (SS / AL) | ||||
SJWM-2580/CS/IS | 6 – 12 Kg / Cm2 | 1800 – 3500 | 100 NB Flange | 62 Mtrs. | 2580 / 2840 | CS / (SS / AL) |
SJWM-2580/CS/NS | 6 – 12 Kg / Cm2 | CS & (SS / AL) | ||||
SJWM-3500/CS/IS | 7 – 12 Kg / Cm2 | 2500 – 5500 | 150 NB Flange | 67 Mtrs. | 3750 | CS & (SS / AL) |
SJWM-3500/CS/NS | 7 – 12 Kg / Cm2 | CS / (SS / AL) | ||||
